Genuine
Product Overview
Panel Specifications
Brand
Rv Power Solar Panel
Model
RVP715N-144TDG
Power Rating
715 W
Cell Type
Mono PERC
Efficiency
21.3%
Manufacture Date
November 2025
Country of Origin
China
Category
Solar Panel
Technical Data
Electrical Specifications
Measured at Standard Test Conditions (STC): 1000W /m², AM1.5, 25°C
| Parameter | Value | Unit |
|---|---|---|
| Maximum Power (Pmax) | 715 | Wp |
| Voltage at Pmax (Vmp) | 47.20 | V |
| Current at Pmax (Imp) | 15.15 | A |
| Open Circuit Voltage (Voc) | 56.40 | V |
| Short Circuit Current (Isc) | 15.98A | A |
| Module Efficiency | 21.3 | % |
| Maximum System Voltage | 1500VDC | V DC |
| Operating Temperature | −40 to +85 | °C |
| Maximum Series Fuse Rating | 30A | |
| Application Class | 0~+3% | |
| Power Sorting | A | |
| Protection Class | || | |
| Weight | 31.0(kg) | |
| Dimension | 2278x1134x30(mm) |
Protection
Warranty Details
Product Warranty
3 Years
Full coverage for manufacturing defects and material failures
Performance Warranty
25 Years
Guaranteed ≥80% of rated power output at end of warranty period
Warranty Expiration
March 15, 2029
Performance warranty valid until this date
Authenticity
Verification Result
Product Verified
This solar panel is registered in our database and has passed all authenticity checks. The serial number, model, and manufacturer details have been confirmed as genuine.
Product Status
Genuine
Warranty Status
Active
CERTIFIED
GENUINE
